Haskel refrigerant pumps are built to move refrigerants across their full operating range — from high‑pressure liquid transfer to vapor recovery, all the way down to deep vacuum levels of 23–27 inches of mercury. This eliminates the need for multiple tools or added components like unloaders, condensers or bypass valves.
The pump automatically transitions as the refrigerant changes phase, allowing operators to complete transfer and evacuation faster, more consistently, and with less setup.
The Haskel model 59025 Refrigerant Recovery Pump transfers refrigerants across all pressure ranges up to 1200 psi, including pulling a vacuum down to 27″ Hg to remove all remnants from the supply bottle.
The Haskel model 59015 Refrigerant Recovery Pump transfers refrigerants across all pressure ranges up to 1200 psi, including pulling a vacuum down to 27″ Hg to remove all remnants from the supply bottle. The Haskel model 59015 pump displacement per cycle 8.9 cu.in.
The pump handles liquid first, then vapor and finally vacuum — maintaining efficiency across each stage of refrigerant recovery and recharge.
Speed adjusts automatically from zero up to maximum output, with the ability to stall or start under load and run dry — ensuring flexibility in unpredictable real‑world recovery scenarios.
Weighing just 13 lb (59015) or 25 lb (59025), these pumps deliver industrial‑grade performance in a compact, field‑ready form factor that operators can carry anywhere.
Core refrigerant workflows where purity, safety and phase‑handling matter most.
For moving refrigerants between storage cylinders, process vessels, and system components with clean, cool, and contamination‑free operation.
Designed to efficiently recover refrigerant from systems in any phase — liquid, vapor, or deep vacuum — and recharge systems with equal precision.
Supports accurate system charging without heat generation, ensuring stable conditions during fill and top‑off operations.
Ideal for reclaiming refrigerants during maintenance, system decommissioning, or environmental compliance workflows.
High‑value niche use cases where reliability and purity are essential.
Safely recovers halon from fire suppression systems without introducing contaminants, preserving agent purity.
Supports environmentally responsible reclaim of legacy refrigerants still present in older HVAC‑R assets.
Ideal for capturing SF₆ from high‑voltage switchgear and utility systems where zero leakage and maximum safety are critical. (Uses the pump’s no‑lubrication gas section and safe pneumatic drive.)
Applications requiring precision, clean handling and phase control.
Supports transfer of CO₂ and other supercritical fluids in controlled conditions, benefiting from cool operation and no electrical hazard.
Handles high‑pressure liquid gases reliably without heat input — enabling stable, efficient product transfer.
Compatible with modern automotive refrigerants including HFO‑1234yf, enabling efficient vehicle AC servicing and charging workflows.
Need guidance selecting the right solution for your process?
Because the pump is pneumatically driven, it generates no heat during liquid transfer and only minor warming during vapor transfer. No lubricants are used in the gas section, ensuring nothing contaminates the refrigerant in any phase. With no electrical components, operators avoid spark risks and enjoy safe operation even in challenging environments. The 59025 model incorporates a distance piece that creates an atmospheric chamber between the air drive and refrigerant sections—preventing cross‑contamination even if the air supply contains impurities.
Pressure Capability: up to 1,200 psi
A refrigerant recovery pump is a compressor that transfers refrigerant from a system into a recovery cylinder without venting harmful gases into the atmosphere — a process required by EPA and global regulations.
Haskel refrigerant pumps specifically move liquid, vapor and vacuum with a single unit, operating across pressures up to 1,200 psi and achieving 23–27” Hg vacuum, enabling complete system evacuation.
