Hydrogen refuelling stations occupy a similar footprint to diesel stations and offer equivalent refuelling times and processes. Thanks to the long vehicle range between stops, refuelling with hydrogen can be operationally equivalent to diesel vehicles. Users will find refuelling with hydrogen is straightforward, fast and easy to use.
Refuelling systems can be configured to meet the necessary operational and refuelling profile for HGVs and typically range from 100kg/day to 2000 kg/day, enough to fuel up to 50 HGVs. In addition to HGVs, this kind of station can refuel a portfolio of vehicles such as buses, waste collection trucks, vans, cars and other light and medium duty vehicles. For trials of a small number of larger vehicles where fast filling is required, smaller portable units with external ground storage could be installed to fast fill HGVs on a back-to-back basis.
Hydrogen refuelling stations can be deployed within either a depot-based environment or on land dedicated for a refuelling hub in or near a logistics park or public station. So whatever type of operation is being set up, stations could be deployed in suitable locations to refuel the fleet. Stations can be designed to meet the specific needs of a fleet and scaled up over time through a modular approach to meet further demand. Thanks to their modular design, stations’ footprint can be tailored to fit into existing depot facilities. With limited space this can be challenging at times, and so a dedicated piece of land for a refuelling hub could make things easier, especially with future growth in mind.
A typical set of considerations for site selection would include:
- Available land for siting hydrogen infrastructure and mobile delivery assets, such as tube trailers
- Locations available allowing existing traffic routes to pass the proposed station location
- The ability to create safety distances between the hydrogen station and other areas of the site
- The availability of utilities and possibilities to upgrade power provision (especially if onsite production is being considered)
- Site access and egress for hydrogen delivery vehicles, such as tube trailers
- Third-party access potential, if within project scope
Hydrogen stations can be sized to refuel small- to medium-sized fleets at a single location. Station providers are working on developing larger facilities and, by 2025, the next generation of stations should be available which will enable higher capacity and faster filling.
For the moment, the most significant development in terms of hydrogen refuelling infrastructure in Europe is the Scandinavian Mediterranean Corridor, which will stretch more than 3,900 miles from Helsinki, Finland, to Valletta, Malta, and feature 17 filling stations. Most countries in Europe are making funding available to station investors and this will result in the development of stations right across the continent for both public and private use.
In summary, HGV manufacturers, third-party logistics providers, refuelling infrastructure developers, large retailers, local authorities and other stakeholders should bear the following points in mind when considering hydrogen as an emission-free alternative to diesel:
- Hydrogen fuel cell technology is reliable and proven.
- The hydrogen refuelling experience is quick, simple and virtually identical to the current experience.
- The main difference between refuelling cars and vans with hydrogen and doing the same with HGVs is the increased volume of fuel required for the latter, and that’s why larger stations will soon become available.
- Current refuelling stations take up a similar footprint to conventional diesel stations and so can be located on existing traffic routes or within depots and logistic parks
- Although HGVs represent a small proportion of the total number of vehicles on the road, they account for 26% of global road transport emissions – eliminating their contribution to greenhouse gas emissions is a quick win.
